Industrial Automatic steel Roller Shutter Door / Heavy Duty Rolling
Shutter Door /Any RAl color steel Roller Shutter Door
Basic Info
| Material | Stainless steel |
| Position | Industry,warehouse,commercial shop |
| MOQ | 1 set |
| Certification | CCC,ISO,CE |
| Origin | Guangzhou, China |
| Color | Any RAl color |
| Sample | Available |
| Size | Can be customized (maximum width: 7m, maximum height: 7m) |
| Type of drive | Manually operated(push up and down)
Motor-operated (remote control or switch button or endless chain)
Function: Safety, theftproof, weather resistant, rustproof, sound
insulation |
Product Destription
We export a very wide range of steel rolling shutter doors for the
industrial places where the opening often require high security and
sometimes in very large sizes.
The galvanized steel industrial roller shutters are the most
popular shutters for industrial applications, such as
industrial factories, industrial warehouse, and more.
Compared to other types of roller shutter doors, the industrial
steel roller shutter doors are one of the most
versatile and cost-effective roller shutter doors.
Normally the industrial steel roller shutter doors are electrically
operated with roller shutter motor, mainly
because it's most large openings, so the industrial steel roller
shutter should be heavy duty.
We do offer manually operated industrial steel roller shutter doors
but they are relatively rare these days in
industrial applications, with electric motor prices being so
competitive. Manual operation is used on smaller
or very low usage roller doors only.
The width and height of a door will often define the model of steel
rolling shutter slats to be used as each have
their limits and depend on the security level required. We produce
82mm and 110mm width steel slats with our
high automatic roll forming machine, which can produce 300 square
meters per day.
Applications
The galvanized steel industrial roller shutters are the most
popular shutters for industrial applications, such as
industrial factories, industrial warehouse, and more.
♦ Factory
♦ Warehouse
♦ and more industrial areas
Key Features / Benefits
♦ Security/ burglar proof
♦ Strong and durable
♦ Energy saving
♦ Cost effective. Compared to other types of roller shutter doors,
galvanized steel roller shutter is way too much cheaper.
♦ Ventilation available. The galvanized steel slats could be
perforated to offer ventilation.
♦ Many color available. The natural color, white, blue, green,
cream, or any other RAL color by powder coating
♦ Easy to install
♦ Low maimaintenance
Drawings
1,Steel bottom rail
2,Plastic insert
3,Steel slat
4,Steel end clip
5,Steel punched slat
Steel guide rail
7,Steel micro-perforated slat
8,Shaft (roller drum)
9,Bearing
10,Left side plate
11,Right side plate
12,Roller shutter motor
13,Manual hoist chain
14,Switch button
15,Remote control
Technical specifications
| Item number | Max width | Max height | Color | Operation way | Options |
| SG110 | 12,000 mm | 9,000 mm | any RAL color by powder coating | manual operation, motorized operation | shutter box, safety sensor, UPS, safety brake, video surveillance |
Curtain:The rolling shutter curtain itself consists of Consisted of solid
interlockig galvanized steel slats, with steel
end clips on both sides of curtain to prevent lateral movement.
Thickness option: 0.8 mm, 1 mm, 1.2 mm
Bottom rail:
♦Material: rollformed galvanized steel
♦With plastic end caps on both sides
♦Dimension:40*70mm,50*100mm Depth*Height
Guide rail:
♦Material: rollformed galvanized steel
♦Dimension:100*60mm, Width*Depth
♦Thickness available: 1.2mm, 1.5mm
♦Windproof guide rails are available if needed
Shaft / Axle:
♦Material: galvanized steel
♦Diameter: 6 inches, 8 inches, 10 inches
♦Wall thickness: 2 mm, 2.5 mm, 3 mm, 4 mm
Mullions: Removable center mullions are available on requiest for
applications were shutter opening
can not be covered by one shutter door.
Side plates / brackets
♦The brackets are manufactured from mild steel and supplied in
premed finish
♦The brackets can only be installed on a structural fixing surface
such as concete, steel columns, steel
angles are normally used to supported the brackets if needed
♦With plates slotted to accommodate shaft or motor mounting.
Operation way:
♦Manual operation by hand or hook (push up & push down)
♦Manual operation by Chain system
♦Automatic operation with motor(remote controls, switch button)
Optional:
♦Shutter box / hood cover
♦Perforated slats, punched slats are available if needed
♦Wicket door
Color Options
Project Photo Gallery
Certification
FAQ of Steel Roll Up Shutter Door
- What are your main steel door products?
A: Our main steel door products are insulated sectional garage
doors, industry door. We can offer different materials such as
polyurethane sandwich panel, aluminum profile with tempered glass,
solid wood, aluminum sheet, laser cut design, and other new
materials available.
- What is the delivery time?
A: 20 days for the standard colors and 30 days for the customized.
Also it depends on the specifications and quantity each order.
Shipment time depends on the location of our customers.
- What is your payment items?
A: Normally we accept 30% for deposit by T/T and the balance would
be arranged before delivery. If you have any other suggestion,
please contact with us.
- Can we place one or two sets for trial?
A: Yes of course, this is the better way of quality check. Also if
you don't required one whole set, we have small sample in stock as
well, it is free of charge, you just need to handle with the
freight. It is a good way to show the sincerity for both of us.
- How can I know the price exactly?
A: The price is based on your specific requirements, it is better
to provide as much as possible information such as color, size,
quantity, market location, sales patterns, all of these would be of
help us to quote the exact price.
- Can I order components instead of the full set of door?
A: Yes, as a factory we welcome business clients purchasing
components of the door, such as panels, hardware's, motors, etc.,
to maximize the advantage of our mutual parties.
